Scientific Calculator In Python Using Tkinter

Introduction

We have created a Scientific Calculator in Python which is a fully functional graphical user interface system that contains everything that IT students and computer-related courses will require for their college projects. The project has the same symbols, operators, and numbers as a regular calculator, however, the user cannot enter a number using their keyboard. Python is a computer language that may be used to do mathematical and scientific calculations.

Click here to get the complete source code of Scientific Calculator in Python

Scientific Calculator in Python using Tkinter: Project Overview

Project Name:	Scientific Calculator in Python using Tkinter
Abstract	It’s a GUI-based project used with the tkinter module to organize all the elements that work under Scientific Calculator in Python.
Language/s Used:	Python
IDE	PyCharm and Thonny(Recommended)
Python version (Recommended):	Python 3.x
Database:	Not used
Type:	Desktop Application
Recommended for	Beginners in Python and intermediates of Tkinter

We will mostly understand our codes using comments. Now, let’s start.

Step.1: Importing Libraries and Designing The Buttons


1
2
3
4
5
6
7
8
import tkinter as tk
from math import *

# used to switch between units of rad, and deg
convert_constant = 1
inverse_convert_constant = 1

btn_params = {'padx': 16, 'pady': 1, 'bd': 4, 'fg': 'white', 'bg': 'black', 'font': ('arial', 18), 'width': 2, 'height': 2, 'relief': 'flat', 'activebackground': "black"}
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

In the above code sample, we imported the essential libraries, such as Tkinter, as well as all of the widget classes, including the message box module. This framework allows Python programmers to easily develop GUI components by utilizing the widgets included in the Tk toolkit. Math module for solving mathematical equations. I designed the buttons using the button function.

Step.2: Defining the Functions of the Calculator


1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
#Functions for the buttons
def fsin(arg):
    return sin(arg * convert_constant)


def fcos(arg):
    return cos(arg * convert_constant)


def ftan(arg):
    return tan(arg * convert_constant)


def arcsin(arg):
    return inverse_convert_constant * (asin(arg))


def arccos(arg):
    return inverse_convert_constant * (acos(arg))


def arctan(arg):
    return inverse_convert_constant * (atan(arg))
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Here we define some functions to implement the Sin, Cos, Tan, Sin-¹, Cos-¹, Tan-¹. To do that we use some predefine python functions such as Sin(), Cos(), Tan(), asin(), acos(), atan().

Step.3: Creating a Display of Calculator


1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
# Here are the methods inside class for all the Buttons in the Scientific Calculator.
class Calculator:
    def __init__(self, master):
        # expression that will be displayed on screen
        self.expression = ""
        # be used to store data in memory
        self.recall = ""
        # self.answer
        self.sum_up = ""
        # create string for text input
        self.text_input = tk.StringVar()
        # assign instance to master
        self.master = master
        # set frame showing inputs and title
        top_frame = tk.Frame(master, width=650, height=10,
                             bd=10, relief='flat', bg='gray')
        top_frame.pack(side=tk.TOP)
        # set frame showing all buttons
        bottom_frame = tk.Frame(
            master, width=650, height=470, bd=2, relief='flat', bg='black')
        bottom_frame.pack(side=tk.BOTTOM)

        # Here is the code for Display of Calculator.
        # entry interface for inputs
        txt_display = tk.Entry(top_frame, font=('arial', 36), relief='flat', bg='black', fg='white', textvariable=self.text_input, width=60, bd=12, justify='right')
        txt_display.pack()

        # row 0
        # left bracket button
        self.btn_left_brack = tk.Button(
            bottom_frame, **btn_params, text="(", border=1, command=lambda: self.btn_click('('))
        self.btn_left_brack.grid(row=0, column=0)
        # right bracket button
        self.btn_right_brack = tk.Button(
            bottom_frame, **btn_params, text=")", command=lambda: self.btn_click(')'))
        self.btn_right_brack.grid(row=0, column=1)
        # takes e to some exponent that you insert into the function
        self.btn_exp = tk.Button(
            bottom_frame, **btn_params, text="exp", command=lambda: self.btn_click('exp('))
        self.btn_exp.grid(row=0, column=2)
        # constant pi
        self.btn_pi = tk.Button(
            bottom_frame, **btn_params, text="π", command=lambda: self.btn_click('pi'))
        self.btn_pi.grid(row=0, column=3)
        # square root
        self.btn_sqrt = tk.Button(
            bottom_frame, **btn_params, text="sqrt", command=lambda: self.btn_click('sqrt('))
        self.btn_sqrt.grid(row=0, column=4)
        # clears self.expression
        self.btn_clear = tk.Button(
            bottom_frame, **btn_params, text="C", command=self.btn_clear_all)
        self.btn_clear.grid(row=0, column=5)
        # deletes last string input
        self.btn_del = tk.Button(
            bottom_frame, **btn_params, text="AC", command=self.btn_clear1)
        self.btn_del.grid(row=0, column=6)
        # inputs a negative sign to the next entry
        self.btn_change_sign = tk.Button(
            bottom_frame, **btn_params, text="+/-", command=self.change_signs)
        self.btn_change_sign.grid(row=0, column=7)
        # division
        self.btn_div = tk.Button(
            bottom_frame, **btn_params, text="/", command=lambda: self.btn_click('/'))
        self.btn_div.grid(row=0, column=8)

        # row 1
        # changes trig function outputs to degrees
        self.btn_Deg = tk.Button(bottom_frame, **btn_params, activeforeground='gray', text="Deg", command=self.convert_deg)
        self.btn_Deg.grid(row=1, column=0)
        # changes trig function outputs to default back to radians
        self.btn_Rad = tk.Button(bottom_frame, **btn_params, foreground='white', activeforeground='Gray', text="Rad", command=self.convert_rad)
        self.btn_Rad.grid(row=1, column=1)
        # cubes a value
        self.cube = tk.Button(bottom_frame, **btn_params, text=u"x\u00B3", command=lambda: self.btn_click('**3'))
        self.cube.grid(row=1, column=2)
        # takes the absolute value of an expression
        self.btn_abs = tk.Button(
            bottom_frame, **btn_params, text="abs", command=lambda: self.btn_click('abs' + '('))
        self.btn_abs.grid(row=1, column=3)
        # 'memory clear' button. Wipes self.recall to an empty string
        self.btn_MC = tk.Button(
            bottom_frame, **btn_params, text="MC", command=self.memory_clear)
        self.btn_MC.grid(row=1, column=4)
        # seven
        self.btn_7 = tk.Button(bottom_frame, **btn_params, text="7", command=lambda: self.btn_click(7))
        self.btn_7.configure(activebackground="black", bg='black')
        self.btn_7.grid(row=1, column=5)
        # eight
        self.btn_8 = tk.Button(bottom_frame, **btn_params, text="8", command=lambda: self.btn_click(8))
        self.btn_8.configure(activebackground="black", bg='black')
        self.btn_8.grid(row=1, column=6)
        # nine
        self.btn_9 = tk.Button(bottom_frame, **btn_params, text="9", command=lambda: self.btn_click(9))
        self.btn_9.configure(activebackground="black", bg='black')
        self.btn_9.grid(row=1, column=7)
        # multiplication
        self.btn_mult = tk.Button(bottom_frame, **btn_params, text="x", command=lambda: self.btn_click('*'))
        self.btn_mult.grid(row=1, column=8)

        # row 2
        # sin function that returns value from -1 to 1 by default
        self.btn_sin = tk.Button(
            bottom_frame, **btn_params, text="sin", command=lambda: self.btn_click('fsin('))
        self.btn_sin.grid(row=2, column=0)
        # cos function that returns value from -1 to 1 by default
        self.btn_cos = tk.Button(
            bottom_frame, **btn_params, text="cos", command=lambda: self.btn_click('fcos('))
        self.btn_cos.grid(row=2, column=1)
        # tan function
        self.btn_tan = tk.Button(bottom_frame, **btn_params, text="tan", command=lambda: self.btn_click('ftan('))
        self.btn_tan.grid(row=2, column=2)
        #
        self.btn_log = tk.Button(bottom_frame, **btn_params, text="log", command=lambda: self.btn_click('log('))
        self.btn_log.grid(row=2, column=3)
        # outputs what is in self.recall
        self.btn_MR = tk.Button(bottom_frame, **btn_params, text="MR", command=self.memory_recall)
        self.btn_MR.grid(row=2, column=4)
        # four
        self.btn_4 = tk.Button(bottom_frame, **btn_params, text="4", command=lambda: self.btn_click(4))
        self.btn_4.configure(activebackground="black", bg='black')
        self.btn_4.grid(row=2, column=5)
        # five
        self.btn_5 = tk.Button(bottom_frame, **btn_params, text="5", command=lambda: self.btn_click(5))
        self.btn_5.configure(activebackground="black", bg='black')
        self.btn_5.grid(row=2, column=6)
        # six
        self.btn_6 = tk.Button(bottom_frame, **btn_params, text="6", command=lambda: self.btn_click(6))
        self.btn_6.configure(activebackground="black", bg='black')
        self.btn_6.grid(row=2, column=7)
        # subtraction
        self.btnSub = tk.Button(bottom_frame, **btn_params, text="-", command=lambda: self.btn_click('-'))
        self.btnSub.grid(row=2, column=8)

        # row 3
        # sin inverse function
        self.btn_sin_inverse = tk.Button(bottom_frame, **btn_params, text=u"sin-\u00B9", command=lambda: self.btn_click('arcsin('))
        self.btn_sin_inverse.grid(row=3, column=0)
        # cos inverse function
        self.btn_cos_inverse = tk.Button(bottom_frame, **btn_params, text=u"cos-\u00B9", command=lambda: self.btn_click('arccos('))
        self.btn_cos_inverse.grid(row=3, column=1)
        # tan inverse function
        self.btn_tan_inverse = tk.Button(bottom_frame, **btn_params, text=u"tan-\u00B9", command=lambda: self.btn_click('arctan('))
        self.btn_tan_inverse.grid(row=3, column=2)
        # takes the natural log
        self.btn_ln = tk.Button(bottom_frame, **btn_params, text="ln", command=lambda: self.btn_click('log1p('))
        self.btn_ln.grid(row=3, column=3)
        # adds current self.expression to self.recall string
        self.btn_M_plus = tk.Button(bottom_frame, **btn_params, text="M+", command=self.memory_add)
        self.btn_M_plus.grid(row=3, column=4)
        # one
        self.btn_1 = tk.Button(bottom_frame, **btn_params, text="1", command=lambda: self.btn_click(1))
        self.btn_1.configure(activebackground="black", bg='black')
        self.btn_1.grid(row=3, column=5)
        # two
        self.btn_2 = tk.Button(bottom_frame, **btn_params, text="2", command=lambda: self.btn_click(2))
        self.btn_2.configure(activebackground="black", bg='black')
        self.btn_2.grid(row=3, column=6)
        # three
        self.btn_3 = tk.Button(bottom_frame, **btn_params, text="3", command=lambda: self.btn_click(3))
        self.btn_3.configure(activebackground="black", bg='black')
        self.btn_3.grid(row=3, column=7)
        # addition
        self.btn_add = tk.Button(
            bottom_frame, **btn_params, text="+", command=lambda: self.btn_click('+'))
        self.btn_add.grid(row=3, column=8)

        # row 4
        # factorial function
        self.btn_fact = tk.Button(bottom_frame, **btn_params, text="n!", command=lambda: self.btn_click('factorial('))
        self.btn_fact.grid(row=4, column=0)
        # square function
        self.btn_sqr = tk.Button(bottom_frame, **btn_params, text=u"x\u00B2", command=lambda: self.btn_click('**2'))
        self.btn_sqr.grid(row=4, column=1)
        # to the power of function
        self.btn_power = tk.Button(bottom_frame, **btn_params, text="x^y", command=lambda: self.btn_click('**'))
        self.btn_power.grid(row=4, column=2)
        # stores previous expression as an answer value
        self.btn_ans = tk.Button(bottom_frame, **btn_params, text="ans", command=self.answer)
        self.btn_ans.grid(row=4, column=3)
        # comma to allow for more than one parameter!
        self.btn_comma = tk.Button(bottom_frame, **btn_params, text=",", command=lambda: self.btn_click(','))
        self.btn_comma.grid(row=4, column=4)
        # zero
        self.btn_0 = tk.Button(bottom_frame, **btn_params, text="0", command=lambda: self.btn_click(0))
        self.btn_0.configure(activebackground="black", bg='black', width=7, bd=5)
        self.btn_0.grid(row=4, column=5, columnspan=2)
        # equals button
        self.btn_eq = tk.Button(bottom_frame, **btn_params, text="=", command=self.btn_equal)
        self.btn_eq.configure(bg='Gray', activebackground='#009999')
        self.btn_eq.grid(row=4, column=7)
        # decimal to convert to float
        self.btn_dec = tk.Button(bottom_frame, **btn_params, text=".", command=lambda: self.btn_click('.'))
        self.btn_dec.grid(row=4, column=8)
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

We created a Calculator class with the following instance variables: ‘op’ (stores the current operator clicked by the user), ‘M’ (stores memory), ‘isTrue 2nd’ (stores True if ‘2nd’ is clicked and activates the second set of scientific functions like sin-1, 10x. ex, y x in place of sin, log, ln, xy), ‘is degree’ (True if ‘deg’ is on, takes radians for trigonometric operations when ‘deg’ is clicked to ‘rad’ and is degree = False) and ‘decimal clicked’ (turns True when user clicks ‘.’)

Step.4: Create functions for the buttons in Calculator


1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
    # allows button you click to be put into self.expression

    def btn_click(self, expression_val):
        if len(self.expression) >= 23:
            self.expression = self.expression
            self.text_input.set(self.expression)
        else:
            self.expression = self.expression + str(expression_val)
            self.text_input.set(self.expression)

    # clears last item in string

    def btn_clear1(self):
        self.expression = self.expression[:-1]
        self.text_input.set(self.expression)
    # adds in a negative sign

    def change_signs(self):
        self.expression = self.expression + '-'
        self.text_input.set(self.expression)
    # clears memory_recall

    def memory_clear(self):
        self.recall = ""

    # adds whatever is on the screen to self.recall

    def memory_add(self):
        self.recall = self.recall + '+' + self.expression
    # uses whatever is stored in memory_recall

    def answer(self):
        self.answer = self.sum_up
        self.expression = self.expression + self.answer
        self.text_input.set(self.expression)
    # uses whatever is stored in memory_recall
    def memory_recall(self):
        if self.expression == "":
            self.text_input.set('0' + self.expression + self.recall)
        else:
            self.text_input.set(self.expression + self.recall)
    # changes self.convert_constant to a string that allows degree conversion when button is clicked
    def convert_deg(self):
        global convert_constant
        global inverse_convert_constant
        convert_constant = pi / 180
        inverse_convert_constant = 180 / pi
        self.btn_Rad["foreground"] = 'White'
        self.btn_Deg["foreground"] = 'RED'
    def convert_rad(self):
        global convert_constant
        global inverse_convert_constant
        convert_constant = 1
        inverse_convert_constant = 1
        self.btn_Rad["foreground"] = 'RED'
        self.btn_Deg["foreground"] = 'white'
    # clears self.expression

    def btn_clear_all(self):
        self.expression = ""
        self.text_input.set("")
    # converts self.expression into a mathematical expression and evaluates it

    def btn_equal(self):
        self.sum_up = str(eval(self.expression))
        self.text_input.set(self.sum_up)
        self.expression = self.sum_up
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Step.5: Making Tkinter Layout


1
2
3
4
5
6
7
# tkinter layout
root = tk.Tk()
b = Calculator(root)
root.title("Scientific Calculator!")
root.geometry("650x490+50+50")
root.resizable(False, False)
root.mainloop()
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

In the end, it is time to start designing the program’s graphical user interface for our Scientific Calculator in Python using Tkinter. We will begin by launching Tkinter and creating a window for the Scientific calculator. In this case, we set the window size to 650×490+50+50, and the window resizability to false.

Complete code for Scientific Calculator in Python using Tkinter


1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
import tkinter as tk
from math import *

# used to switch between units of rad, and deg
convert_constant = 1
inverse_convert_constant = 1

btn_params = {'padx': 16, 'pady': 1, 'bd': 4, 'fg': 'white', 'bg': 'black', 'font': ('arial', 18),
              'width': 2, 'height': 2, 'relief': 'flat', 'activebackground': "black"}

#Functions for the buttons
def fsin(arg):
    return sin(arg * convert_constant)


def fcos(arg):
    return cos(arg * convert_constant)


def ftan(arg):
    return tan(arg * convert_constant)


def arcsin(arg):
    return inverse_convert_constant * (asin(arg))


def arccos(arg):
    return inverse_convert_constant * (acos(arg))


def arctan(arg):
    return inverse_convert_constant * (atan(arg))


# Here are the methods inside class for all the Buttons in the Scientific Calculator.
class Calculator:
    def __init__(self, master):
        # expression that will be displayed on screen
        self.expression = ""
        # be used to store data in memory
        self.recall = ""
        # self.answer
        self.sum_up = ""
        # create string for text input
        self.text_input = tk.StringVar()
        # assign instance to master
        self.master = master
        # set frame showing inputs and title
        top_frame = tk.Frame(master, width=650, height=10,
                             bd=10, relief='flat', bg='gray')
        top_frame.pack(side=tk.TOP)
        # set frame showing all buttons
        bottom_frame = tk.Frame(
            master, width=650, height=470, bd=2, relief='flat', bg='black')
        bottom_frame.pack(side=tk.BOTTOM)

        # Here is the code for Display of Calculator.
        # entry interface for inputs
        txt_display = tk.Entry(top_frame, font=('arial', 36), relief='flat', bg='black', fg='white', textvariable=self.text_input, width=60, bd=12, justify='right')
        txt_display.pack()

        # row 0
        # left bracket button
        self.btn_left_brack = tk.Button(
            bottom_frame, **btn_params, text="(", border=1, command=lambda: self.btn_click('('))
        self.btn_left_brack.grid(row=0, column=0)
        # right bracket button
        self.btn_right_brack = tk.Button(
            bottom_frame, **btn_params, text=")", command=lambda: self.btn_click(')'))
        self.btn_right_brack.grid(row=0, column=1)
        # takes e to some exponent that you insert into the function
        self.btn_exp = tk.Button(
            bottom_frame, **btn_params, text="exp", command=lambda: self.btn_click('exp('))
        self.btn_exp.grid(row=0, column=2)
        # constant pi
        self.btn_pi = tk.Button(
            bottom_frame, **btn_params, text="π", command=lambda: self.btn_click('pi'))
        self.btn_pi.grid(row=0, column=3)
        # square root
        self.btn_sqrt = tk.Button(
            bottom_frame, **btn_params, text="sqrt", command=lambda: self.btn_click('sqrt('))
        self.btn_sqrt.grid(row=0, column=4)
        # clears self.expression
        self.btn_clear = tk.Button(
            bottom_frame, **btn_params, text="C", command=self.btn_clear_all)
        self.btn_clear.grid(row=0, column=5)
        # deletes last string input
        self.btn_del = tk.Button(
            bottom_frame, **btn_params, text="AC", command=self.btn_clear1)
        self.btn_del.grid(row=0, column=6)
        # inputs a negative sign to the next entry
        self.btn_change_sign = tk.Button(
            bottom_frame, **btn_params, text="+/-", command=self.change_signs)
        self.btn_change_sign.grid(row=0, column=7)
        # division
        self.btn_div = tk.Button(
            bottom_frame, **btn_params, text="/", command=lambda: self.btn_click('/'))
        self.btn_div.grid(row=0, column=8)

        # row 1
        # changes trig function outputs to degrees
        self.btn_Deg = tk.Button(bottom_frame, **btn_params, activeforeground='gray', text="Deg", command=self.convert_deg)
        self.btn_Deg.grid(row=1, column=0)
        # changes trig function outputs to default back to radians
        self.btn_Rad = tk.Button(bottom_frame, **btn_params, foreground='white', activeforeground='Gray', text="Rad", command=self.convert_rad)
        self.btn_Rad.grid(row=1, column=1)
        # cubes a value
        self.cube = tk.Button(bottom_frame, **btn_params, text=u"x\u00B3", command=lambda: self.btn_click('**3'))
        self.cube.grid(row=1, column=2)
        # takes the absolute value of an expression
        self.btn_abs = tk.Button(
            bottom_frame, **btn_params, text="abs", command=lambda: self.btn_click('abs' + '('))
        self.btn_abs.grid(row=1, column=3)
        # 'memory clear' button. Wipes self.recall to an empty string
        self.btn_MC = tk.Button(
            bottom_frame, **btn_params, text="MC", command=self.memory_clear)
        self.btn_MC.grid(row=1, column=4)
        # seven
        self.btn_7 = tk.Button(bottom_frame, **btn_params, text="7", command=lambda: self.btn_click(7))
        self.btn_7.configure(activebackground="black", bg='black')
        self.btn_7.grid(row=1, column=5)
        # eight
        self.btn_8 = tk.Button(bottom_frame, **btn_params, text="8", command=lambda: self.btn_click(8))
        self.btn_8.configure(activebackground="black", bg='black')
        self.btn_8.grid(row=1, column=6)
        # nine
        self.btn_9 = tk.Button(bottom_frame, **btn_params, text="9", command=lambda: self.btn_click(9))
        self.btn_9.configure(activebackground="black", bg='black')
        self.btn_9.grid(row=1, column=7)
        # multiplication
        self.btn_mult = tk.Button(bottom_frame, **btn_params, text="x", command=lambda: self.btn_click('*'))
        self.btn_mult.grid(row=1, column=8)

        # row 2
        # sin function that returns value from -1 to 1 by default
        self.btn_sin = tk.Button(
            bottom_frame, **btn_params, text="sin", command=lambda: self.btn_click('fsin('))
        self.btn_sin.grid(row=2, column=0)
        # cos function that returns value from -1 to 1 by default
        self.btn_cos = tk.Button(
            bottom_frame, **btn_params, text="cos", command=lambda: self.btn_click('fcos('))
        self.btn_cos.grid(row=2, column=1)
        # tan function
        self.btn_tan = tk.Button(bottom_frame, **btn_params, text="tan", command=lambda: self.btn_click('ftan('))
        self.btn_tan.grid(row=2, column=2)
        #
        self.btn_log = tk.Button(bottom_frame, **btn_params, text="log", command=lambda: self.btn_click('log('))
        self.btn_log.grid(row=2, column=3)
        # outputs what is in self.recall
        self.btn_MR = tk.Button(bottom_frame, **btn_params, text="MR", command=self.memory_recall)
        self.btn_MR.grid(row=2, column=4)
        # four
        self.btn_4 = tk.Button(bottom_frame, **btn_params, text="4", command=lambda: self.btn_click(4))
        self.btn_4.configure(activebackground="black", bg='black')
        self.btn_4.grid(row=2, column=5)
        # five
        self.btn_5 = tk.Button(bottom_frame, **btn_params, text="5", command=lambda: self.btn_click(5))
        self.btn_5.configure(activebackground="black", bg='black')
        self.btn_5.grid(row=2, column=6)
        # six
        self.btn_6 = tk.Button(bottom_frame, **btn_params, text="6", command=lambda: self.btn_click(6))
        self.btn_6.configure(activebackground="black", bg='black')
        self.btn_6.grid(row=2, column=7)
        # subtraction
        self.btnSub = tk.Button(bottom_frame, **btn_params, text="-", command=lambda: self.btn_click('-'))
        self.btnSub.grid(row=2, column=8)

        # row 3
        # sin inverse function
        self.btn_sin_inverse = tk.Button(bottom_frame, **btn_params, text=u"sin-\u00B9", command=lambda: self.btn_click('arcsin('))
        self.btn_sin_inverse.grid(row=3, column=0)
        # cos inverse function
        self.btn_cos_inverse = tk.Button(bottom_frame, **btn_params, text=u"cos-\u00B9", command=lambda: self.btn_click('arccos('))
        self.btn_cos_inverse.grid(row=3, column=1)
        # tan inverse function
        self.btn_tan_inverse = tk.Button(bottom_frame, **btn_params, text=u"tan-\u00B9", command=lambda: self.btn_click('arctan('))
        self.btn_tan_inverse.grid(row=3, column=2)
        # takes the natural log
        self.btn_ln = tk.Button(bottom_frame, **btn_params, text="ln", command=lambda: self.btn_click('log1p('))
        self.btn_ln.grid(row=3, column=3)
        # adds current self.expression to self.recall string
        self.btn_M_plus = tk.Button(bottom_frame, **btn_params, text="M+", command=self.memory_add)
        self.btn_M_plus.grid(row=3, column=4)
        # one
        self.btn_1 = tk.Button(bottom_frame, **btn_params, text="1", command=lambda: self.btn_click(1))
        self.btn_1.configure(activebackground="black", bg='black')
        self.btn_1.grid(row=3, column=5)
        # two
        self.btn_2 = tk.Button(bottom_frame, **btn_params, text="2", command=lambda: self.btn_click(2))
        self.btn_2.configure(activebackground="black", bg='black')
        self.btn_2.grid(row=3, column=6)
        # three
        self.btn_3 = tk.Button(bottom_frame, **btn_params, text="3", command=lambda: self.btn_click(3))
        self.btn_3.configure(activebackground="black", bg='black')
        self.btn_3.grid(row=3, column=7)
        # addition
        self.btn_add = tk.Button(
            bottom_frame, **btn_params, text="+", command=lambda: self.btn_click('+'))
        self.btn_add.grid(row=3, column=8)

        # row 4
        # factorial function
        self.btn_fact = tk.Button(bottom_frame, **btn_params, text="n!", command=lambda: self.btn_click('factorial('))
        self.btn_fact.grid(row=4, column=0)
        # square function
        self.btn_sqr = tk.Button(bottom_frame, **btn_params, text=u"x\u00B2", command=lambda: self.btn_click('**2'))
        self.btn_sqr.grid(row=4, column=1)
        # to the power of function
        self.btn_power = tk.Button(bottom_frame, **btn_params, text="x^y", command=lambda: self.btn_click('**'))
        self.btn_power.grid(row=4, column=2)
        # stores previous expression as an answer value
        self.btn_ans = tk.Button(bottom_frame, **btn_params, text="ans", command=self.answer)
        self.btn_ans.grid(row=4, column=3)
        # comma to allow for more than one parameter!
        self.btn_comma = tk.Button(bottom_frame, **btn_params, text=",", command=lambda: self.btn_click(','))
        self.btn_comma.grid(row=4, column=4)
        # zero
        self.btn_0 = tk.Button(bottom_frame, **btn_params, text="0", command=lambda: self.btn_click(0))
        self.btn_0.configure(activebackground="black", bg='black', width=7, bd=5)
        self.btn_0.grid(row=4, column=5, columnspan=2)
        # equals button
        self.btn_eq = tk.Button(bottom_frame, **btn_params, text="=", command=self.btn_equal)
        self.btn_eq.configure(bg='Gray', activebackground='#009999')
        self.btn_eq.grid(row=4, column=7)
        # decimal to convert to float
        self.btn_dec = tk.Button(bottom_frame, **btn_params, text=".", command=lambda: self.btn_click('.'))
        self.btn_dec.grid(row=4, column=8)

    # functions
    # allows button you click to be put into self.expression

    def btn_click(self, expression_val):
        if len(self.expression) >= 23:
            self.expression = self.expression
            self.text_input.set(self.expression)
        else:
            self.expression = self.expression + str(expression_val)
            self.text_input.set(self.expression)

    # clears last item in string

    def btn_clear1(self):
        self.expression = self.expression[:-1]
        self.text_input.set(self.expression)

    # adds in a negative sign

    def change_signs(self):
        self.expression = self.expression + '-'
        self.text_input.set(self.expression)

    # clears memory_recall

    def memory_clear(self):
        self.recall = ""

    # adds whatever is on the screen to self.recall

    def memory_add(self):
        self.recall = self.recall + '+' + self.expression

    # uses whatever is stored in memory_recall

    def answer(self):
        self.answer = self.sum_up
        self.expression = self.expression + self.answer
        self.text_input.set(self.expression)

    # uses whatever is stored in memory_recall

    def memory_recall(self):
        if self.expression == "":
            self.text_input.set('0' + self.expression + self.recall)
        else:
            self.text_input.set(self.expression + self.recall)

    # changes self.convert_constant to a string that allows degree conversion when button is clicked

    def convert_deg(self):
        global convert_constant
        global inverse_convert_constant
        convert_constant = pi / 180
        inverse_convert_constant = 180 / pi
        self.btn_Rad["foreground"] = 'white'
        self.btn_Deg["foreground"] = 'RED'

    def convert_rad(self):
        global convert_constant
        global inverse_convert_constant
        convert_constant = 1
        inverse_convert_constant = 1
        self.btn_Rad["foreground"] = 'RED'
        self.btn_Deg["foreground"] = 'white'

    # clears self.expression

    def btn_clear_all(self):
        self.expression = ""
        self.text_input.set("")

    # converts self.expression into a mathematical expression and evaluates it

    def btn_equal(self):
        self.sum_up = str(eval(self.expression))
        self.text_input.set(self.sum_up)
        self.expression = self.sum_up


# tkinter layout
root = tk.Tk()
b = Calculator(root)
root.title("Scientific Calculator!")
root.geometry("650x490+50+50")
root.resizable(False, False)
root.mainloop()
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Output:

Conclusion

In this article, we built a Scientific Calculator in Python using Tkinter and defined what happens when a user interacts with a UI element. Using Frame widgets to create containers/windows in which to arrange UI components. Positioning Button widgets within a Frame widget using Tkinter’s Layout Manager. The grid layout manager was chosen for the Calculator application due to its precision compared to alternative layout techniques.

Best 100+ Python Projects with source code

Also Read:

Scientific Calculator in Python using Tkinter
