GUI Tic Tac Toe game in Java

Today we are going to build a small but cool project together which is a GUI Tic Tac Toe game in Java. This game is a classic programming problem that is going to set your foundation for logic building in programming. So let’s start with it.

Project Overview: GUI Tic Tac Toe game in Java

Project Name:GUI Tic Tac Toe game in Java
AbstractIt’s a GUI-based project used with the swing library to organize all the elements that work under the Tic Tac Toe game.
Language/s Used:Java
IDEVs code(Recommended)
Java version (Recommended):latest
Database:Not used
Type:Desktop Application
Approx time:1 hour

What you will learn from the GUI Tic Tac Toe game in Java:

  • Handling Classes and Objects creation (very important as this is the standard used in industry-ready programs)
  • Dealing with data structures like 2D arrays
  • Functions, Loops, Conditionals, and variables
  • And lastly, Java Swing and Java awt for creating a beautiful User Interface

Features of the Tic Tac Toe game in Java are:

  • Two players can play
  • The corresponding scores of both players will be visible
  • Either of the players wins or its a tie
  • New Game to play fresh

Setting up the development environment:

Create a folder on the desktop of your computer with the name of TicTacToe.

Now open the VS code editor and open the terminal by clicking on the left-side top icon.

open terminal in vs code

Navigate to the folder location that we just created for our project by doing cd TicTacToe. Now we are in the project folder.

navigate to TicTacToe folder

First, download two images in the folder that we will require to create the X symbol and a cool console game icon as a logo. Click here to download.

Create a file with the name TicTacToe.java (don’t forget to add .java extension).

TicTacToe.java file

Complete code for GUI Tic Tac Toe game in Java:

Now copy the below lines(with the button available on the top right of the code) of the code into the file. I have provided the necessary comments in the code to better understand the code.

import java.awt.Dimension;
import java.awt.Color;
import java.awt.event.*;
import java.awt.Graphics;
import java.awt.Image;
import java.awt.Font;
import java.awt.Toolkit;
import javax.swing.JButton;
import javax.swing.JFrame;
import javax.swing.JPanel;
import javax.swing.ImageIcon;
import java.io.*;
import java.util.Scanner;

public class TicTacToe extends JPanel implements ActionListener {

    // core logic variables
    boolean playerX; // true if player X's turn, false if player O's turn
    boolean gameDone = false; // true if game is over
    int winner = -1; // 0 if X wins, 1 if O wins, -1 if no winner yet
    int player1wins = 0, player2wins = 0; // number of wins for each player
    int[][] board = new int[3][3]; // 0 if empty, 1 if X, 2 if O

    // paint variables
    int lineWidth = 5; // width of the lines
    int lineLength = 270; // length of the lines
    int x = 15, y = 100; // location of first line
    int offset = 95; // square width
    int a = 0; // used for drawing the X's and O's
    int b = 5; // used for drawing the X's and O's
    int selX = 0; // selected square x
    int selY = 0; // selected square y

    // COLORS
    Color turtle = new Color(152, 109, 142);
    Color orange = new Color(255, 165, 0);
    Color offwhite = new Color(0xf7f7f7);
    Color darkgray = new Color(239, 227, 208);
    Color pink = new Color(130, 92, 121);

    // COMPONENTS
    JButton jButton;

    // CONSTRUCTOR
    public TicTacToe() {
        Dimension size = new Dimension(420, 300); // size of the panel
        setPreferredSize(size);
        setMaximumSize(size);
        setMinimumSize(size);
        addMouseListener(new XOListener()); // add mouse listener
        jButton = new JButton("New Game");
        jButton.addActionListener(this); // add action listener
        jButton.setBounds(315, 210, 100, 30); // set button location
        add(jButton); // add button to panel
        resetGame();
    }

    public void resetGame() {
        playerX = true;
        winner = -1;
        gameDone = false;
        for (int i = 0; i < 3; i++) {
            for (int j = 0; j < 3; j++) {
                board[i][j] = 0; // all spots are empty
            }
        }
        getJButton().setVisible(false); // hide the button
    }

    public void paintComponent(Graphics page) {
        super.paintComponent(page);
        drawBoard(page);
        drawUI(page);
        drawGame(page);
    }

    public void drawBoard(Graphics page) {
        setBackground(turtle);
        page.setColor(darkgray);
        page.fillRoundRect(x, y, lineLength, lineWidth, 5, 30);
        page.fillRoundRect(x, y + offset, lineLength, lineWidth, 5, 30);
        page.fillRoundRect(y, x, lineWidth, lineLength, 30, 5);
        page.fillRoundRect(y + offset, x, lineWidth, lineLength, 30, 5);
    }

    public void drawUI(Graphics page) {
        // SET COLOR AND FONT
        page.setColor(pink);
        page.fillRect(300, 0, 120, 300);
        Font font = new Font("Helvetica", Font.PLAIN, 20);
        page.setFont(font);

        // SET WIN COUNTER
        page.setColor(offwhite);
        page.drawString("Win Count", 310, 30);
        page.drawString(": " + player1wins, 362, 70);
        page.drawString(": " + player2wins, 362, 105);

        // DRAW score X
        ImageIcon xIcon = new ImageIcon("orangex.png");
        Image xImg = xIcon.getImage();
        Image newXImg = xImg.getScaledInstance(27, 27, java.awt.Image.SCALE_SMOOTH);
        ImageIcon newXIcon = new ImageIcon(newXImg);
        page.drawImage(newXIcon.getImage(), 44 + offset * 1 + 190, 47 + offset * 0, null);

        // DRAW score O
        page.setColor(offwhite);
        page.fillOval(43 + 190 + offset, 80, 30, 30);
        page.setColor(darkgray);
        page.fillOval(49 + 190 + offset, 85, 19, 19);

        // DRAW WHOS TURN or WINNER
        page.setColor(offwhite);
        Font font1 = new Font("Serif", Font.ITALIC, 18);
        page.setFont(font1);

        if (gameDone) {
            if (winner == 1) { // x
                page.drawString("The winner is", 310, 150);
                page.drawImage(xImg, 335, 160, null);
            } else if (winner == 2) { // o
                page.drawString("The winner is", 310, 150);
                page.setColor(offwhite);
                page.fillOval(332, 160, 50, 50);
                page.setColor(darkgray);
                page.fillOval(342, 170, 30, 30);
            } else if (winner == 3) { // tie
                page.drawString("It's a tie", 330, 178);
            }
        } else {
            Font font2 = new Font("Serif", Font.ITALIC, 20);
            page.setFont(font2);
            page.drawString("", 350, 160);
            if (playerX) {
                page.drawString("X 's Turn", 325, 180);
            } else {
                page.drawString("O 's Turn", 325, 180);
            }
        }
        // DRAW LOGO
        Image cookie = Toolkit.getDefaultToolkit().getImage("logo.png");
        page.drawImage(cookie, 345, 235, 30, 30, this);
        Font c = new Font("Courier", Font.BOLD + Font.CENTER_BASELINE, 13);
        page.setFont(c);
        page.drawString("Tic Tac Toe", 310, 280);
    }

    public void drawGame(Graphics page) {
        for (int i = 0; i < 3; i++) {
            for (int j = 0; j < 3; j++) {
                if (board[i][j] == 0) {

                } else if (board[i][j] == 1) {
                    ImageIcon xIcon = new ImageIcon("orangex.png");
                    Image xImg = xIcon.getImage();
                    page.drawImage(xImg, 30 + offset * i, 30 + offset * j, null);
                } else if (board[i][j] == 2) {
                    page.setColor(offwhite);
                    page.fillOval(30 + offset * i, 30 + offset * j, 50, 50);
                    page.setColor(turtle);
                    page.fillOval(40 + offset * i, 40 + offset * j, 30, 30);
                }
            }
        }
        repaint();
    }

    public void checkWinner() {
        if (gameDone == true) {
            System.out.print("gameDone");
            return;
        }
        // vertical
        int temp = -1;
        if ((board[0][0] == board[0][1])
                && (board[0][1] == board[0][2])
                && (board[0][0] != 0)) {
            temp = board[0][0];
        } else if ((board[1][0] == board[1][1])
                && (board[1][1] == board[1][2])
                && (board[1][0] != 0)) {
            temp = board[1][1];
        } else if ((board[2][0] == board[2][1])
                && (board[2][1] == board[2][2])
                && (board[2][0] != 0)) {
            temp = board[2][1];

            // horizontal
        } else if ((board[0][0] == board[1][0])
                && (board[1][0] == board[2][0])
                && (board[0][0] != 0)) {
            temp = board[0][0];
        } else if ((board[0][1] == board[1][1])
                && (board[1][1] == board[2][1])
                && (board[0][1] != 0)) {
            temp = board[0][1];
        } else if ((board[0][2] == board[1][2])
                && (board[1][2] == board[2][2])
                && (board[0][2] != 0)) {
            temp = board[0][2];

            // diagonal
        } else if ((board[0][0] == board[1][1])
                && (board[1][1] == board[2][2])
                && (board[0][0] != 0)) {
            temp = board[0][0];
        } else if ((board[0][2] == board[1][1])
                && (board[1][1] == board[2][0])
                && (board[0][2] != 0)) {
            temp = board[0][2];
        } else {

            // CHECK FOR A TIE
            boolean notDone = false;
            for (int i = 0; i < 3; i++) {
                for (int j = 0; j < 3; j++) {
                    if (board[i][j] == 0) {
                        notDone = true;
                        break;
                    }
                }
            }
            if (notDone == false) {
                temp = 3;
            }
        }
        if (temp > 0) {
            winner = temp;
            if (winner == 1) {
                player1wins++;
                System.out.println("winner is X");
            } else if (winner == 2) {
                player2wins++;
                System.out.println("winner is O");
            } else if (winner == 3) {
                System.out.println("It's a tie");
            }
            gameDone = true;
            getJButton().setVisible(true);
        }
    }

    public JButton getJButton() {
        return jButton;
    }

    public void setPlayerXWins(int a) {
        player1wins = a;
    }

    public void setPlayerOWins(int a) {
        player2wins = a;
    }

    public static void main(String[] args) {
        JFrame frame = new JFrame("Tic Tac Toe");
        frame.getContentPane();

        TicTacToe gamePanel = new TicTacToe();
        frame.add(gamePanel);

        frame.addWindowListener(new WindowAdapter() {
            public void windowOpened(WindowEvent e) {
                try {
                    File file = new File("score.txt");
                    Scanner sc = new Scanner(file);
                    gamePanel.setPlayerXWins(Integer.parseInt(sc.nextLine()));
                    gamePanel.setPlayerOWins(Integer.parseInt(sc.nextLine()));
                    sc.close();
                } catch (IOException io) {
                    // file doesnt exist
                    File file = new File("score.txt");
                }
            }

            public void windowClosing(WindowEvent e) {
                try {
                    PrintWriter pw = new PrintWriter("score.txt");
                    pw.write("");
                    pw.write(gamePanel.player1wins + "\n");
                    pw.write(gamePanel.player2wins + "\n");
                    pw.close();
                } catch (FileNotFoundException e1) {
                }
            }
        });
        frame.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
        frame.setResizable(false);
        frame.pack();
        frame.setVisible(true);
    }

    private class XOListener implements MouseListener {

        public void mouseClicked(MouseEvent event) {
            selX = -1;
            selY = -1;
            if (gameDone == false) {
                a = event.getX();
                b = event.getY();
                int selX = 0, selY = 0;
                if (a > 12 && a < 99) {
                    selX = 0;
                } else if (a > 103 && a < 195) {
                    selX = 1;
                } else if (a > 200 && a < 287) {
                    selX = 2;
                } else {
                    selX = -1;
                }

                if (b > 12 && b < 99) {
                    selY = 0;
                } else if (b > 103 && b < 195) {
                    selY = 1;
                } else if (b > 200 && b < 287) {
                    selY = 2;
                } else {
                    selY = -1;
                }
                if (selX != -1 && selY != -1) {

                    if (board[selX][selY] == 0) {
                        if (playerX) {
                            board[selX][selY] = 1;
                            playerX = false;
                        } else {
                            board[selX][selY] = 2;
                            playerX = true;
                        }
                        checkWinner();
                        System.out.println(" CLICK= x:" + a + ",y: " + b + "; selX,selY: " + selX + "," + selY);

                    }
                } else {
                    System.out.println("invalid click");
                }
            }
        }

        public void mouseReleased(MouseEvent event) {
        }

        public void mouseEntered(MouseEvent event) {
        }

        public void mouseExited(MouseEvent event) {
        }

        public void mousePressed(MouseEvent event) {
        }
    }

    @Override
    public void actionPerformed(ActionEvent e) {
        resetGame();
    }

}

Output for GUI Tic Tac Toe game in Java:

Now, hit the run button near the top of the main method or go to the left top corner and find the run button. And here is the final look.

output 1 for GUI Tic Tac Toe game in Java

When the winner is O:

Output 2 for GUI Tic Tac Toe game in Java

When there is a tie:

Output 3 for GUI Tic Tac Toe game in Java

We are done!!! Hope you enjoyed building this project on the GUI Tic Tac Toe game in Java as much as I enjoyed creating it for you.

Thanks for reading this article.
